Panduit Barbty® Metal Pawl Cable Ties

Metal Tooth Locking Mechanism In Plenum Rated Nylon Tie

Panduit Barb-ty® Metal Pawl Cable Ties Features

  • Plenum Rated For In Wall Use
  • Colors: Black or Natural
  • UV Stabilized
  • Operating Temperature: -40° C - 85°C
  • Material: Nylon 66 (PA66) UL94-2v Flame
  • Dome-Top head: Smooth, round edges; easy for installers to handle
  • Stainless steel locking barb: Provides consistent performance, reliability, and infinite adjustability through entire bundle range
  • High tensile strength: Exceeds industry and Aerospace Standards SAE AS23190A; available in four tensile strengths
  • Low thread force: Reduces installer fatigue; increases productivity
  • Anti-slip strap body: Ribbed and stippled strap body prevents axial and lateral movement

Metal pawl cable ties are specifically designed zip ties that have a metal tooth locking mechanism implemented in a fully nylon 6-6 body. This metal tooth addition ensures that the locking mechanism will not break.

Click for More Details or Description

Metal Pawl Does Not Increase Tensile Strength

Product Details

Product Specifications

Are we missing the specification you need? Please go to our Contact Us page and submit your question to us, or call 1-877-284-7760

Material Nylon 6.6
Application General
Color Black
Cross Section Standard
Locking Style Locking
Plenum-Rated Yes, AH-2
Length In (mm) 8.00 (203)
Thickness In (mm) 0.04 (1.2)
Bundle Diameter Range In. (mm) 0.06 (1.5) - 2.00 (51)
CE Compliant Yes
CSA Certified Yes
Mil. Std. Part Number NA
UL 62275 Compliant (Type 2S, 21S) Yes
UL Listed (E56854) Yes
UL Recognized (E56854) No
Continuous Use Temperature Range -76°F (-60°C) - 185°F (85°C)
Environment Plenum
Installation Temperature -4°F (-20°C) - 32°F (0°C)
Max. Bundle Diameter (In.) 2
Max. Bundle Diameter (mm) 51
Max. Continuous Use Temperature 185°F (85°C)
Min. Bundle Diameter (In.) 0.06
Min. Bundle Diameter (mm) 1.5
Min. Loop Tensile Strength (Lbs.) 50
Min. Loop Tensile Strength (N) 222 lbs
Operating Temperature -76°F (-60°C) - 185°F (85°C)
Thickness (In.) 0.045
Thickness (mm) 1.1
Width In (mm) 0.18 (4.7)
RoHS Compliancy Status Compliant
Min. Order Qty. 1,000
